BELLIGER ACE

Description

All-in-one mobile C-arm with flat panel detector (FPD). Intended use: Medical imaging and surgical guidance procedures. Key features: - All-in-one integrated design with 860mm free space for flexible placement and operation - 27-inch monitor, selectable 4K UHD/FHD - Digital Subtraction Angiography (DSA) capability - Advanced image processing: Auto Bright Control (ABC), Dynamic Noise Reduction (DNR), motion correction and metal artifact correction - 15.6" operation panel with three selectable imaging style settings - DICOM 3.0 compliant with dose information display (DAP, CAK, AKR) - Proprietary ZENIS IV PLUS software with motion and metal correction algorithms Technical specifications: - Detector: 20x20cm CMOS or 21x21cm TFT flat panel - Generator: 3.2kW, single or dual-focus X-ray tube - Dose modes: High/Middle/Low - Classification: Mobile fluoroscopic X-ray system

Specifications

Free space

860mm

Monitor

27-inch, selectable 4K UHD/FHD

Operation panel

15.6"

Detector

20x20cm CMOS or 21x21cm TFT flat panel

Generator

3.2kW, single or dual-focus X-ray tube

Dose modes

High/Middle/Low

Classification

Mobile fluoroscopic X-ray system
