HeartSave Y AED (Semi-Automatic)

Description

Semi-automatic AED for first responders and lay users in which the rescuer triggers the shock at the touch of a button. Uses a biphasic truncated exponential (BTE) waveform with 10-360 J escalating, individually configurable energy, about 7 s to 200 J and 14 s to 360 J, and a child button for paediatric use. Short voice prompts and a metronome guide CPR, with an optional 4.3" LCD (800 x 480 px) showing CPR animation, CPR quality and the ECG, and an optional external CPR-feedback sensor for compression depth and rate. It has 3 GB memory with USB export, a 24 V / 2.4 Ah LiMnO2 battery (up to 5 years, 230 shocks at 200 J), IP55 protection, 0-55 °C operation and optional LTE / WiFi remote management; 29.6 x 22.0 x 9.7 cm, approx. 2.5 kg with battery, ERC-2025 compliant.

Specifications

Dimensions

29.6 x 22.0 x 9.7 cm

Weight

approx. 2.5 kg with battery

Waveform

biphasic truncated exponential (BTE)

Energy

10-360 J escalating

Memory

3 GB

Battery

24 V / 2.4 Ah LiMnO2

IP Rating

IP55
