HAMILTON-C1 Ventilator

Description

The HAMILTON-C1 serves ICU, PICU, and NICU settings, emergency departments, step-down units, and long-term acute care facilities, and supports intrahospital transport for adult, pediatric, and neonatal patients. Ventilation modes include volume- and flow-controlled ventilation, volume-targeted adaptive pressure control, pressure-controlled ventilation, ASV, noninvasive ventilation, high-flow nasal cannula therapy, and nCPAP modes for neonatal support. It has an 8.4-inch detachable monitor (640 x 480 pixels). Battery runtime is 4 hours with one hot-swappable battery; the ventilation unit weighs just 4.9 kg (16.9 kg with trolley) in a compact 310 x 210 x 245 mm housing. Key technologies include ASV, IntelliSync+ for real-time synchronization, a Dynamic Lung panel, IntelliCuff automated cuff pressure management, and volumetric capnography. It includes an integrated high-performance turbine (no compressed air required), remote HAMILTON-H900 humidifier control, an integrated synchronized pneumatic nebulizer, SpeakValve compatibility for tracheostomized patients, and a CPR ventilation mode, operating at 43 dB.

Specifications

Display size

8.4-inch

Display resolution

640 x 480 pixels

Battery runtime

4 hours

Weight

4.9 kg (16.9 kg with trolley)

Dimensions

310 x 210 x 245 mm

Noise level

43 dB
