HeartSave myPAD 678 AED (Semi-Automatic, 4.3" Touchscreen)
Contact for price
- Condition
- New
- Availability
- On order
- Brand
- Primedic
- Product code
- P-011192
Sold by
Al Hattan for Medical Appliances Al
Description
Semi-automatic version of the HeartSave myPAD with a 4.3" colour touch LCD (800 x 480 px); shock delivered at the touch of a button. Weight approx. 1.1 kg, 151 x 151 x 76 mm. Compact AED (151 x 151 mm) with biphasic truncated exponential (BTE) waveform auto-compensated to patient impedance, delivering 150/170/200 J for adults and 50 J in child mode via the child button. IP66 dust- and waterproof, 1.6 m drop-tested, operating from 0 to 55 °C, with 8 GB memory, up to 6 selectable languages and ERC-2025 guidelines. Uses pre-connectable electrodes (5-year shelf life) and a 5-year LiMnO2 battery (12 V / 2.8 Ah, 130 shocks at 200 J) or an optional 12-year rechargeable Li-ion battery (230 shocks at 200 J); optional CPR-feedback sensor and LTE / WiFi IoT connectivity. 8-year warranty.
Specifications
- Weight
- approx. 1.1 kg
- Dimensions
- 151 x 151 x 76 mm
- Display
- 4.3" colour touch LCD (800 x 480 px)
- Waveform
- biphasic truncated exponential (BTE)
- Energy Output (Adults)
- 150/170/200 J
- Energy Output (Child)
- 50 J
- Ingress Protection
- IP66 dust- and waterproof
- Drop Test
- 1.6 m drop-tested
- Operating Temperature
- 0 to 55 °C
- Memory
- 8 GB
- Languages
- up to 6 selectable languages
- Guidelines
- ERC-2025
- Battery (Standard)
- 5-year LiMnO2 battery (12 V / 2.8 Ah, 130 shocks at 200 J)
- Warranty
- 8-year warranty
