Aquilion ONE / PRISM Edition CT Scanner

Description

Premium area detector CT scanner from the Aquilion ONE family with deep learning reconstruction and spectral imaging. It uses a 160 x 0.5 mm detector (320-slice coneXact reconstruction) with 8 cm or optional 16 cm z-axis coverage, 0.275 second rotation and an optional 100 kW generator. The 78 cm bore, 47 cm wide couch and 315 kg (694 lb) couch capacity suit a broad patient range. PIQE super-resolution reconstruction, AiCE, deep learning spectral reconstruction and the SilverBeam filter for low-dose lung screening are key features.

Specifications

detector

160 x 0.5 mm

z-axis coverage

8 cm or optional 16 cm

rotation time

0.275 second

generator

optional 100 kW

bore

78 cm

couch width

47 cm

couch capacity

315 kg (694 lb)
