TBA-nx360 Automated Clinical Chemistry Analyzer

Description

Compact automated clinical chemistry analyzer in Canon's 900-test-per-hour class with automatic reagent loading, designed for round-the-clock operation without stopping testing.

Specifications

Maximum Number of Test Items

Up to 200 items (colorimetric and calculated items)

Processing Speed

Colorimetric: up to 900 tests/hour; Electrolyte: up to 675 tests/hour

Analytical Method

Endpoint method, rate method, electrode method

Sample Dispensing Volume

1.5–35.0 µL/test (0.1 µL step); sample clot (blockage) detection function as standard

Inter-specimen Carryover

Below 0.1 ppm

Reagent Dispensing Volume

First reagent (R1): 45–345 µL (1 µL step); Second reagent (R2): 20–160 µL (1 µL step)

Final Reaction Volume

80–360 µL

Sampler

Rack sampler (150 samples); STAT priority measurement position can be set arbitrarily; sample ID unit as standard

Sample Container

Blood collection tubes, sample cups

Reagent Container

R1/R2 bottle-integrated reagent kit

Reagent Storage

Up to 70 positions

Reaction Vessel

Hard glass (optical path length 5 mm)

Reaction Time

Approx. 10 minutes

Constant Temperature Method

Water bath method (37 °C)

Stirring

Piezo stirring method (2 units)

Measurement Wavelength

340–804 nm (16 wavelengths)

Dimensions (W × D × H)

1190 × 1181 × 1345 mm

Mass

Approx. 712 kg

Power Supply

Biochemical analysis module: single-phase AC 200 V; System control module: single-phase AC 200 V; Immunoassay module (optional): single-phase AC 200 V

Power Consumption

Biochemical analysis module: up to 3.0 kVA; System control module: up to 1.6 kVA; Immunoassay module (optional): up to 3.0 kVA

Options

Compatible with sample transport system connection
