TBA-1500FR Automated Clinical Chemistry Analyzer

Description

Automated clinical chemistry analyzer in Canon's 1,300-test-per-hour class with dual dispensing lines for efficient high-speed processing and compatibility with domestic reagents.

Specifications

Maximum Request Items

Up to 100 items

Processing Speed

Colorimetry: up to 1300 tests/hour; Electrolyte: up to 600 tests/hour

Analytical Method

Endpoint method, rate method, electrode method

Photometric Method

Direct photometric method for reaction tubes, 1 or 2 wavelengths

Measurement Wavelength

340~804 nm (16 wavelengths)

Reaction Time

About 10 minutes

Sample Dispensing Volume

1.5~35.0 μL/Test (0.1 μL step); Standard sample clog detection function

Inter-Specimen Carryover

Below 0.1 ppm

Reagent Dispensing Volume

First reagent: 20~278 μL (1 μL step); Second reagent: 20~200 μL (1 μL step)

Final Reaction Solution Volume

80~280 μL

Sampler

Rack sampler; Up to 200 samples; Equipped with cup sensor, standard specimen ID unit

STAT Position

1 location

Reagent Storage

R1: Up to 73 runs; R2: Up to 73 runs

Reagent Container

100 mL, 90 mL, 70 mL, 55 mL, 50 mL, 20 mL

Reaction Vessel

Made of hard glass (optical path length 5 mm)

Constant Temperature Method

Water bath system

Stirring

Piezo stirring method (2 locations)

Power Supply

Analyzer unit: AC 200 V

Power Consumption

Analyzer unit: 3 kVA

External Dimensions

1896 (W) × 1150 (D) × 1437 (H) mm

Weight

Approximately 780 kg

Options

55 mL bottle reagent rack, reagent barcode reader
