TBA-2000FR Automated Clinical Chemistry Analyzer

Description

Automated clinical chemistry analyzer in Canon's 1,600-test-per-hour class focused on precision, simple operation and eco-friendly design with stable accuracy.

Specifications

Testing throughput

1,600-test-per-hour

Simultaneous Measurement Items

100 Items

Processing Speed

Colorimetric up to 1600 tests/hour; Electrolyte: up to 600 tests/hour

Analytical Method

End Method, Rate Method, Electrode Method

Sample Dispensing Volume

1.5~35.0 μL / Test (0.1 μL step)

Inter-Specimen Carryover

Below 0.1 ppm

Reagent Dosage

R1: 20~278 μL/reagent (1 μL step); R2: 0, 20~200 μL/reagent (1 μL step)

Final Reaction Solution Volume

80~280 μL

STAT Positions

1 location

Sample Container

Blood collection tubes, sample cups

Reagent Storage

R1: 56 bottles (up to 65 bottles when using the 55 mL bottle reagent rack); R2: 56 bottles (up to 65 bottles when using the 55 mL bottle reagent rack)

Reagent Container

100 mL, 90 mL, 70 mL, 55 mL, 50 mL, 20 mL

Reaction Disk

Discrete method

Reaction Vessel

Made of hard glass (optical path length 5 mm)

Reaction Time

About 10 minutes

Constant Temperature Method

Water bath system

Reaction Temperature

37 ℃

Stirring

Piezo stirring method (2 locations)

Measurement Wavelength

340~804 nm (16 wavelengths)

Metering Method

Direct photometric method for reaction tubes, 1 or 2 wavelengths

Online Interface

RS232C

Data Processing

Multi-point calibration curve, calibration curve expiration display, calibration curve history, automatic calibration, reaction time course (33 points), reagent remaining quantity display, reagent bottle crossing, reagent bottle sharing, reagent shortage skip, sample shortage skip, obstacle detection, quality control (daily, monthly, real-time QC), carryover avoidance cleaning, reaction testing, flex rate, reaction tube skipping, multiple measurement, automatic sample dilution, automatic retest requests, smart reporting, OSS function, multi-assay function, recalculation, color correction, serum information, inter-item calculations, process monitor, automatic startup, automatic shutdown, reaction tube analyzer, user ID/password registration, light source lamp monitor

Options

55 mL bottle reagent rack, reagent barcode unit

External Dimensions

Analytical section: 1896 (W) × 1150 (D) × 1437 (H) mm

Mass

Analytical section: approx. 780 kg

Power Supply

Analytical section: AC 200 V

Power Consumption

Analytical section: Up to 3 kVA
